PET Geotextile Nonwoven For Road Construction

PET Geotextile Nonwoven For Road Construction -Staple fiber needle-punched nonwoven geotextiles use PET staple fibers as the predominant uncooked fabric and are produced by using non-woven technology. Good flexibility, corrosion resistance and oxidation resistance.


●Material: PET fiber

●Color: white, black, gray

●Length: 50m-100m

●Width: 0.5-6m

●Certificate: CE/ISO9001

●Type: Acupuncture



Contact Now E-Mail Telephone WhatsApp
Product Details

PET Geotextile Nonwoven For Road Construction

PET non-woven geotextiles are easy to construct and have good application effects. Geotextiles are used to enhance the tensile strength and deformation resistance of the soil, enhance the stability of the building structure, and improve the quality of the soil. Widely used in railways, highways, tunnels and other projects, with the functions of anti-filtration, reinforcement, protection, drainage and so on.


Product Features:

The thickness of the product is suitable, it is easy to mix with the asphalt pavement, and it forms an isolation layer after being combined with the viscous layer oil, which has the characteristics of waterproof and warm;

High water permeability—under the pressure of soil and water, it can still maintain good water permeability. Due to its light weight, it can be packaged according to certain requirements, and it is very convenient for transportation, storage and construction.

Utilize the good air permeability and water permeability of the geotextile to let the water flow through, thereby effectively retaining the loss of sand and soil.

The surface is rough and not easy to slide. When laying, the rough side of the surface after special treatment is facing upwards to increase the friction coefficient and increase the bonding force of the surface layer to prevent being rolled up and damaged by the wheels during construction, and at the same time, it can inhibit the slippage of vehicles and paver on the cloth ;

Application:

The product has excellent water permeability, filterability and durability, and can be widely used in railways, highways, sports halls, dams, hydraulic structures, tunnels, coastal tidal flats, reclamation, environmental protection and other projects.

Function:

  • Utilize the proper air permeability and water permeability of geotextiles to let water go with the go with the flow through, thereby correctly maintaining the misplaced sand.

  • Widely used in cement concrete pavement and roadbed, slight weight, immoderate strength, immoderate tensile strength, fantastic for every challenging and flexible pavement, prolonged company life, helps to cease road reflection cracks;

  • Use geotextiles to adorn the tensile strength and deformation resistance of the soil, enhance the steadiness of the establishing structure, and beautify the tremendous of the soil.

PET Geotextile Nonwoven For Road Construction PET Geotextile Nonwoven For Road Construction

Specifications

Staple Fiber Needled Non-woven Geotextile Technical  Specifications ( GB/T17638-1998)

No.

Item

Specifications

Note

100

150

200

250

300

350

400

450

500

600

800

1

Unit area mass  deviation

-8

-8

-8

-8

-7

-7

-7

-7

-6

-6

-6



2

Thickness mm≥

0.9

1.3

1.7

2.1

2.4

2.7

3.0

3.3

3.6

4.1

5.0

3

Width deviation

-0.5

4

Breaking strength

2.5

4.5

6.5

8.0

9.5

11

12.5

14.0

16.0

19.0

25.0

Vertical and horizontal

5

Elongation at break %

20-100

6

CBR bursting strength

0.3

0.6

0.8

1.2

1.4

1.8

2.1

2.4

2.7

3.2

4.0



7

Equivalent aperture

0.07-0.2



8

Vertical permeability  coefficient

K*(10-1~10-3)

K=1.0-9.9

9

Tear strength

0.08

0.12

0.16

0.20

0.24

0.28

0.33

0.38

0.42

0.46

0.6

Vertical and  horizontal

Packing of PET Geotextile Nonwoven For Road Construction

You can freely choose PE film or PP woven bag for outer packaging, and there are paper tubes of different sizes inside the product for you to choose freely.

PET Geotextile Nonwoven For Road Construction  PET Geotextile Nonwoven For Road Construction

FAQ

Q1: Are you trading company or manufacturer?

A: We have our own geosynthetics production factory.

Q2: How long is your delivery time?

A: Generally it is 5-10 days if the goods are in stock. If the goods are not in stock, it is 15-20 days, it is calculated according to the quantity of the order.

Q3: Do you provide samples? Is it free or extra?

A: Yes, we can provide samples for free, but do not pay for shipping.

Q4: What is your payment terms?

A:Payment: 30% deposit paid by T/T with confirming order, 70% balance paid by T/T before delivery.

Q5: What is your MOQ?

A: Our MOQ is USD 3000.

PET Geotextile Nonwoven For Road Construction  PET Geotextile Nonwoven For Road Construction  PET Geotextile Nonwoven For Road Construction

Staple Fiber Needled Non-woven Geotextile Technical  Specifications ( GB/T17638-1998)

No.

Item

Specifications

Note

100

150

200

250

300

350

400

450

500

600

800

1

Unit area mass  deviation

-8

-8

-8

-8

-7

-7

-7

-7

-6

6

-6



2

Thickness mm≥

0.9

1.3

1.7

2.1

2.4

2.7

3.0

3.3

3.6

4.1

5.0

3

Width deviation

-0.5

4

Breaking strength

2.5

4.5

6.5

8.0

9.5

11

12.5

14.0

16.0

19.0

25.0

Vertical and horizontal

5

Elongation at break %

20-100

6

CBR bursting strength

0.3

0.6

0.8

1.2

1.4

1.8

2.1

2.4

2.7

3.2

4.0



7

Equivalent aperture

0.07-0.2



8

Vertical permeability  coefficient

K*(10-1~10-3

K=1.0-9.9

9

Tear strength

0.08

0.12

0.16

0.20

0.24

0.28

0.33

0.38

0.42

0.46

0.6

Vertical and  horizontal
