PET Geotextile Needle Punched Non-woven Fabric
PET Geotextile Needle Punched Non-woven Fabric -PET Geotextile Needle Punched Non-woven Fabric can replace traditional engineering materials and construction methods, making construction safer, contributing to environmental protection, and solving basic problems in engineering construction more economically, effectively and durably.
●Material:Polyester
●Color: White,Black,Orange
●Unit weight:100gsm-800gsm
●Length: 50m-100m
●Width: 1-6.2m
●Certificate: CE /ISO9001
●Type: Needle Punched
PET Geotextile Needle Punched Non-woven Fabric
Product features
●Excellent permeability and plane drainage performance
●Excellent high temperature resistance
●Excellent creep resistance
●Anti-ultraviolet light
●Excellent ductility
Function:
●Isolation
That is to use geotextiles to isolate building materials (such as soil and sand, sand and gravel, soil and concrete, etc.) with different physical properties (particle size, distribution, consistency and density, etc.). Make two or more materials not to be lost or mixed, maintain the overall structure and function of the material, and strengthen the load bearing capacity of the structure.
●Filter
When water flows from the fine-grained soil layer to the coarse-grained soil layer, the good air permeability and water permeability of the needle-punched geotextile are used to allow the water to flow through. And it effectively intercepts soil particles, fine sand, small stones, etc. to maintain the stability of water and soil engineering.
●Drainage
PET Geotextile Needle Punched Non-woven Fabric is a good water-conducting material, which can form a drainage channel in the soil structure and remove excess liquid and gas inside the soil structure.
Product implementation standards: national standard (GB/T 17639-2008)
| Filament Spunbonded Needled Non-woven Geotextile Technical Specifications | ||||||||||
| Item | Index | |||||||||
| Index breaking strength（KN/m） | 4.5 | 7.5 | 10 | 15 | 20 | 25 | 30 | 40 | 50 | |
| 1 | Vertical and horizontal rupture strength / (KN/ m) | 4.5 | 7.5 | 10 | 15 | 20 | 25 | 30 | 40 | 50 |
| 2 | Vertical and horizontal standard strength corresponding to elongation % | 40-80 | ||||||||
| 3 | CBR bursting strength /KN | 0.8 | 1.6 | 1.9 | 2.9 | 3.9 | 5.3 | 6.4 | 7.9 | 8.5 |
| 4 | Vertical and horizontal tearing strength /KN | 0.14 | 0.21 | 0.28 | 0.42 | 0.56 | 0.70 | 0.82 | 1.10 | 1.25 |
| 5 | Equivalent aperture O90(95)>/mm | 0.05-0.20 | ||||||||
| 6 | Vertical permeability coefficient | K*(10-1～10-3）and K=1.0～9.9 | ||||||||
| 7 | Thickness / mm≥ | 0.8 | 1.2 | 1.6 | 2.2 | 2.8 | 3.4 | 4.2 | 5.5 | 6.8 |
| 8 | Width deviation | -0.5 | ||||||||
| 9 | Unit area mass deviation | -5 | ||||||||
Packing of PET Geotextile Needle Punched Non-woven Fabric
You can freely choose PE film or PP woven bag for outer packaging, and there are paper tubes of different sizes inside the product for you to choose freely.
Strength of the company
The company has its own factory and independent product production equipment, specializing in the production and operation of filament geotextiles, short-filament geotextiles, geomembranes, geogrids, and geogrids. The annual production of geotextiles is more than 30 million square meters. The products have CE and ISO certifications, and have been identified as leading enterprises of similar products by Chinese authorities, and there are professional after-sales personnel to provide assistance to customers. The products have been exported to Japan, Russia, the United States, Europe and Southeast Asian countries many times, and have won unanimous praise.
