Factory Direct Sale Polypropylene Geotextile For Road Works
Factory Direct Sale Polypropylene Geotextile For Road Works-Staple fiber needle-punched geotextiles have good mechanical properties, good water permeability, high strength, corrosion resistance, anti-aging, isolation, reverse filtration, reinforcement and other functions, can adapt to uneven base layers, and can resist external damage during construction , small creep, used in reinforcement of railway subgrade, maintenance of highway pavement, protection of sports halls and dams.
●Material: Polypropylene fiber
●Color: white, black, gray
●Length: 50m-100m
●Width: 0.5-6m
●Certificate: CE/ISO9001
●Type: Acupuncture
Factory Direct Sale Polypropylene Geotextile For Road Works
Staple-fiber needle-punched geotextiles are widely used in the reinforcement of asphalt pavement, cement concrete pavement and roadbed. The surface is rough and not easy to slide.
Product Features:
Increase the stability of gravel slopes and reinforced soil, prevent water and soil loss and soil freezing damage at low temperatures.
Creep resistance: The creep resistance of geotextiles is better than other geotextiles, so the long-term effect is good. It is resistant to the erosion of common chemical substances in the soil and the corrosion of gasoline and diesel oil;
Geotextile has good water conductivity, it can form a drainage channel inside the soil, and discharge excess liquid and gas in the soil structure.
The geotextile has a good elongation under certain stress, so that it can adapt to the uneven and irregular base surface;
Application:
The product has excellent water permeability, filterability and durability, and can be widely used in railways, highways, sports halls, dams, hydraulic structures, tunnels, coastal tidal flats, reclamation, environmental protection and other projects.
Function:
Corrosion resistance, long-term corrosion resistance in soil and water with different pH;
Utilize the precise air and water permeability of needle-punched geotextiles to allow water to leak, effectively retain soil particles, spun yarns, small stones, etc., and maintain the stability of water and soil engineering.
Eliminate water seepage around the tunnel, reduce the external water pressure on the lining and seepage around the buildings.
High breaking strength, up to 20KN/m or more, good creep resistance and corrosion resistance;
Specifications
Staple Fiber Needled Non-woven Geotextile Technical Specifications ( GB/T17638-1998) | |||||||||||||
No. | Item | Specifications | Note | ||||||||||
100 | 150 | 200 | 250 | 300 | 350 | 400 | 450 | 500 | 600 | 800 | |||
1 | Unit area mass deviation | -8 | -8 | -8 | -8 | -7 | -7 | -7 | -7 | -6 | -6 | -6 |
|
2 | Thickness mm≥ | 0.9 | 1.3 | 1.7 | 2.1 | 2.4 | 2.7 | 3.0 | 3.3 | 3.6 | 4.1 | 5.0 | |
3 | Width deviation | -0.5 | |||||||||||
4 | Breaking strength | 2.5 | 4.5 | 6.5 | 8.0 | 9.5 | 11 | 12.5 | 14.0 | 16.0 | 19.0 | 25.0 | Vertical and horizontal |
5 | Elongation at break % | 20-100 | |||||||||||
6 | CBR bursting strength | 0.3 | 0.6 | 0.8 | 1.2 | 1.4 | 1.8 | 2.1 | 2.4 | 2.7 | 3.2 | 4.0 |
|
7 | Equivalent aperture | 0.07-0.2 |
| ||||||||||
8 | Vertical permeability coefficient | K*(10-1~10-3) | K=1.0-9.9 | ||||||||||
9 | Tear strength | 0.08 | 0.12 | 0.16 | 0.20 | 0.24 | 0.28 | 0.33 | 0.38 | 0.42 | 0.46 | 0.6 | Vertical and horizontal |
Packing of Factory direct sale polypropylene geotextile for road works
You can freely choose PE film or PP woven bag for outer packaging, and there are paper tubes of different sizes inside the product for you to choose freely.
FAQ
1. Who are we?
We are a specialized company engaged in the R&D, production and sales of geosynthetics.
2. How can we guarantee the quality?
Always a pre-production sample before mass production;
Always carry out final inspection before shipment;
3. What can you buy from us?
Geotextile, bentonite waterproof blanket GCL, geocell, geomembrane
4. Why should you buy from us not from other suppliers?
Shandong Taiwei Engineering Materials Co., Ltd. is a manufacturer integrating geomembrane, geotextile and bentonite waterproof blanket GCL.
5. What services can we provide?
Accepted delivery terms: FOB, CFR, CIF;
Accepted payment currencies: USD,RMB.
Accepted payment methods: T/T, PayPal;
Language: English, Chinese
Staple Fiber Needled Non-woven Geotextile Technical Specifications ( GB/T17638-1998) | |||||||||||||
No. | Item | Specifications | Note | ||||||||||
100 | 150 | 200 | 250 | 300 | 350 | 400 | 450 | 500 | 600 | 800 | |||
1 | Unit area mass deviation | -8 | -8 | -8 | -8 | -7 | -7 | -7 | -7 | -6 | 6 | -6 |
|
2 | Thickness mm≥ | 0.9 | 1.3 | 1.7 | 2.1 | 2.4 | 2.7 | 3.0 | 3.3 | 3.6 | 4.1 | 5.0 | |
3 | Width deviation | -0.5 | |||||||||||
4 | Breaking strength | 2.5 | 4.5 | 6.5 | 8.0 | 9.5 | 11 | 12.5 | 14.0 | 16.0 | 19.0 | 25.0 | Vertical and horizontal |
5 | Elongation at break % | 20-100 | |||||||||||
6 | CBR bursting strength | 0.3 | 0.6 | 0.8 | 1.2 | 1.4 | 1.8 | 2.1 | 2.4 | 2.7 | 3.2 | 4.0 |
|
7 | Equivalent aperture | 0.07-0.2 |
| ||||||||||
8 | Vertical permeability coefficient | K*(10-1~10-3) | K=1.0-9.9 | ||||||||||
9 | Tear strength | 0.08 | 0.12 | 0.16 | 0.20 | 0.24 | 0.28 | 0.33 | 0.38 | 0.42 | 0.46 | 0.6 | Vertical and horizontal |
